Technical DataPower supply: 24V DC / 3APower input: max. 72 WConnection: pluggable screw terminalEnvironmental conditions: EN 50090-2-2Ambient temperature: –5 to +35°CStorage temperature: –10 to +60°CRelative humidity (non-condensing): 5% to 80%Mechanical data:Installation: MDRC 4 MWDimensions (W x H x D) in mm: 72 x 90 x 63Housing: plasticProtection class: IP20 (according to EN 60529)Interfaces:Ethernet via RJ45 socketKNX®: twisted pair via terminal (for Art. No. 10516 and 10526)Audio Input: 3.5 mm phone connector for Line In Loudspeaker connection: 2 x 20W at 4O Pluggable screw terminal up to 3.6mm2USB 2.0: 4 USB sticks, each up to 8GB (audio data)Features:KNX® bus connectionCan be used both as a streaming client or as a serverAudio input for external sources (automatic or manual switching configurable)xPL package (xPL hub and ExPL plug-in) for connectingthe audio module to the EIBPORT and dynamic coverdisplayHigh quality integrated digital sound processor (DSP)DSP (Audio) profiles selectableEfficient Class-D amplifierSoftware requirements:Operating system: anyCommunication: Network interfaceBrowser: current standard browser
